PTFE Teflon conveyor belt deviation position inspection and solution

Let us learn PTFE Teflon conveyor belt deviation position inspection and solution!

(1) Check the axis coincidence degree
Check the misalignment of the horizontal axis of the idler and the vertical axis of the PTFE Teflon conveyor belt. If the misalignment value exceeds 3mm, the long mounting holes on both sides of the roller set should be used for adjustment. The specific method is which side of the PTFE Teflon conveyor belt is heavier, which side of the roller group moves forward in the direction of the Teflon conveyor belt, or the other side moves to the right.

(2) Check bearing error
Check the error values of the two planes of the head and tail card racks with seated bearings. If the error between the two planes exceeds 1mm, adjust the two planes to the same plane. The adjustment method of the top roller is: if the PTFE Teflon conveyor belt deviates to the right direction of the roller, the seated bearing on the right side of the roller should move forward and in the middle or the seated bearing on the left side should move to the right; if the PTFE Teflon conveyor belt If the drum deviates to the left direction, the seated bearing on the left side of the drum should move forward or the seated bearing on the right side should move to the right. The adjustment method of the tail roller is exactly the opposite to that of the top roller.

(3) Check the position of conveyed objects
Check the location of raw materials on PTFE Teflon high-temperature conveyor belts. The raw material is not vertically centered on the cross section of the PTFE Teflon conveyor belt, which will cause the conveyor belt to deviate in direction. If the raw material deviates to the right, the PTFE Teflon conveyor belt deviates to the left, and vice versa. When using, try to keep the material vertically centered. In order to reduce or prevent the direction deviation of this type of PTFE Teflon conveyor belt, the baffle can be raised and the position and position of the material can be changed.
